I will design embedded lte pcb with sim7600g, rf antenna, camera and kicad layout
Power Electronics Engineer
I’m Daniel C, a Power Electronics Engineer specializing in advanced PCB design and power conversion systems. I work on IGBT inverter boards, gate driver circuits, UPS systems, solar inverters, battery...
Über diesen Service
I build compact cellular embedded boards around SIM7600G for connected camera, remote monitoring and IoT applications. The design brings the modem, RF antenna path, camera hardware and supporting interfaces together on a practical KiCad PCB.
What I offer
- SIM7600G LTE integration
- RF antenna and matching network
- 50Ω RF routing
- Camera sensor/module interface
- SIM card interface
- MicroSD storage
- USB, UART and GPIO
- GNSS support where required
- DC/DC and LDO power sections
- Battery input and charging
- ESD/TVS protection
- 4-layer PCB layout
- KiCad schematic and PCB design
- BOM, Gerbers and manufacturing files
What you will get
You will receive an organized embedded LTE board designed around your modem, camera, antenna, power source, enclosure and required peripherals, with the necessary files for fabrication and assembly.
Why choose me
- Focused RF and cellular PCB approach
- Practical component placement
- Clean antenna and signal routing
- Power and grounding considerations
- KiCad based editable design
- Manufacturing focused workflow
Message me with your SIM7600G variant, camera sensor, antenna, board dimensions and power requirements, and we can define the PCB architecture for your project.
FAQ
Can you integrate SIM7600G with a camera on the same PCB?
Yes. I can combine the LTE modem, camera interface, SIM circuit, power section and supporting peripherals.
Can you design the LTE antenna section?
Yes. I can handle the RF path, antenna connector, matching components, controlled-impedance routing and RF grounding.
Can you use a 4 layer PCB?
Yes. I can develop the stackup and routing around your PCB manufacturer's actual fabrication specifications
Can you prepare the design for JLCPCB?
Yes. I can prepare Gerbers, BOM, pick and place and other manufacturing outputs according to the required fabrication rules.
Can you add MicroSD or GNSS?
Yes. MicroSD, GNSS and other peripherals can be included according to the SIM7600G variant and system architecture.
